I-Beam Mounts

Our most flexible and versatile mounting system is used with all of our large capacity hoists. The addition of a rolling I-Beam Trolley Top allows many Beta Max Hoists to adapt to existing I-Beams. If the horizontal trolley is not necessary Beta Max offers a Fixed I-Beam Top which firmly holds the hoist stationery on the I-Beam.

I-Beam Trolley

  • Lift Capacity: 2,000 lb
  • Headroom: 31.00 in.
  • 1/2 Ton Trolley (2.66” – 6.5” Flange Width)
  • 1 Ton Trolley (2.66” – 8.5” Flange Width)
  • Material delivery made easy with I-Beam Trolley that moves along the full length of the beam
  • Customize forward and backward cantilever to your unique job site requirements

I-Beam Suspension Bracket

  • Steel plate with saddle and pins to grab flange of I-Beam and hang it under horizontal member of scaffold frame.
  • Allows you to install your own I-Beam to existing scaffolding anywhere on your job site.

All Beta Max Mounting Systems can be customized to your job site specifications.

Available Mounts

Specifications Sheet I-Beam

Portable Hoist Mounting Options
